Atlas Copco GA7 Oil-injected Air Compressor and Spare Parts

Atlas Copco GA7 oil-injected compressor excels in mid-range industrial performance with enhanced airflow stability and smart unload algorithm for dynamic energy optimization. Featuring 8,000-hour filtration and heavy-duty coolers, it ensures reliable operation in woodworking, metal fabrication, and recycling plants.

All Spare Parts are factory-certified Atlas Copco originals—guaranteeing minimal maintenance, extended service intervals, and uncompromised air purity. Experience adaptive pressure control and seamless integration with genuine GA7 technology. Contact us for robust solutions tailored to your production demands!

Parts NO.

Name

1089915402 1089 9154 02: Key
1202640000 1202 6400 00: Hinge
0147124403 0147 1244 03: Hexagon bolt
3001232100 3001 2321 00: Washer
1622089900 1622 0899 00: Plate
1619275800 1619 2758 00: Seal

0147196308

0147 1963 08: Hexagon bolt

1088080327 1088 0803 27: Grommet
1622117300 1622 1173 00: Baffle
0147196308 0147 1963 08: Hexagon bolt
1079992083 1079 9920 83: Label website
1079992372 1079 9923 72: Decal
1622352780 1622 3527 80: Panel
1622352780 1622 3527 80: Panel

0686930005

0686 9300 05: Plug

1513043100 1513 0431 00: Door lock
1513043100 1513 0431 00: Door lock
1079990348 1079 9903 48: Warning label
1622080880 1622 0808 80: Door
1513043100 1513 0431 00: Door lock
1513043100 1513 0431 00: Door lock
1616298700 1616 2987 00: Plug

1622085600

1622 0856 00: Frame

0147196308 0147 1963 08: Hexagon bolt
0147196308 0147 1963 08: Hexagon bolt
0147196308 0147 1963 08: Hexagon bolt
0147196308 0147 1963 08: Hexagon bolt
0696514104 0696 5141 04: Cable gland

0697860924

0697 8609 24: Lock nut

0147196308 0147 1963 08: Hexagon bolt
0147196308 0147 1963 08: Hexagon bolt
0147196308 0147 1963 08: Hexagon bolt
0147196308 0147 1963 08: Hexagon bolt
0226325600 0226 3256 00: Screw

0147196308

0147 1963 08: Hexagon bolt

0147196308

0147 1963 08: Hexagon bolt

0147196308 0147 1963 08: Hexagon bolt
0147196308 0147 1963 08: Hexagon bolt
1089906801 1089 9068 01: Key
1088130102 1088 1301 02: Cable strip
0690112501 0690 1125 01: House mark

Parts NO.

Name

0226325600 0226 3256 00: Screw
1622080500 1622 0805 00: Panel
1079990348 1079 9903 48: Warning label
1622116280 1622 1162 80: Door
1079990348 1079 9903 48: Warning label
1619770500 1619 7705 00: Lock

1079992569

1079 9925 69: Label

1613864600 1613 8646 00: Decal
1088100103 1088 1001 03: Warning mark
1622084780 1622 0847 80: Roof
1079290303 1079 2903 03: Panel pin
0266210700 0266 2107 00: Nut
1079990255 1079 9902 55: Label

1622086681

1622 0866 81: Baffle

1079992394 1079 9923 94: Label
1079992394 1079 9923 94: Label
1622463153 1622 4631 53: Decal
1622463153 1622 4631 53: Decal
1622463153 1622 4631 53: Decal
1088100101 1088 1001 01: Warning mark

1089912505

1089 9125 05: Round disk

1900071012 1900 0710 12: Elektronikon® II B+
1622080280 1622 0802 80: Baffle
0147196308 0147 1963 08: Hexagon bolt
1088080327 1088 0803 27: Grommet
0147116903 0147 1169 03: Hexagon bolt
3001231500 3001 2315 00: Washer
0346100207 0346 1002 07: Clamp

0147196285

0147 1962 85: Hex. bolt

0346100207 0346 1002 07: Clamp
0147196285 0147 1962 85: Hex. bolt
1622100000 1622 1000 00: Grating
1622095300 1622 0953 00: Grating
0147132503 0147 1325 03: Hexagon bolt
3000027434 3000 0274 34: Washer

0147124703

0147 1247 03: Hexagon bolt

3000027464 3000 0274 64: Washer
0348010212 0348 0102 12: Clamp
1622080380 1622 0803 80: Panel
0690111600 0690 1116 00: Left panel

Parts NO.

Name

1622354101 1622 3541 01: Switch
0605830099 0605 8300 99: Bushing
1089069850 1089 0698 50: Ring ferrit
1900071194 1900 0711 94: Interface card
1089061227 1089 0612 27: Fuse
1622617680 1622 6176 80: Control box

1622617700

1622 6177 00: Door

1624068800 1624 0688 00: Hinge
1202658400 1202 6584 00: Seal
1624065510 1624 0655 10: Assembly
3031233500 3031 2335 00: Washer
0256211000 0256 2110 00: Nut
3031231800 3031 2318 00: Washer

0266210700

0266 2107 00: Nut

1622327100 1622 3271 00: Lock
1622093682 1622 0936 82: Panel
0147124703 0147 1247 03: Hexagon bolt
0301232100 0301 2321 00: Washer
0560440141 0560 4401 41: Cross
0605870109 0605 8701 09: Bushing

0693312500

0693 3125 00: O-ring

1089057470 1089 0574 70: Temp. sensor
1622066304 1622 0663 04: Cable
0698514071 0698 5140 71: Cable gland
1088080327 1088 0803 27: Grommet

1088080326

1088 0803 26: Grommet

1088130102 1088 1301 02: Cable strip
1625517702 1625 5177 02: Wiring
0346100021 0346 1000 21: Pipe clamp

Parts NO.

Name

1089050630 1089 0506 30: End bracket
1089050660 1089 0506 60: Terminal
1089061201 1089 0612 01: Fuse holder
1089061206 1089 0612 06: Fuse holder
1089061279 1089 0612 79: Fuse

1089924128

1089 9241 28: A-meter

1089933789 1089 9337 89: Contact block
1089944531 1089 9445 31: Main switch
1089948206 1089 9482 06: Logic module
1089951112 1089 9511 12: Socket
1089951155 1089 9511 55: Relay
1089958115 1089 9581 15: Hour meter

1622354001

1622 3540 01: Cable

1622356200 1622 3562 00: Decal
1625521900 1625 5219 00: Label
1900209699 1900 2096 99: Cubicle
0090140002 0090 1400 02: Mounting rail
0090140002 0090 1400 02: Mounting rail
0697980922 0697 9809 22: Nut
0697980925 0697 9809 25: Nut

0697981030

0697 9810 30: Plug

0698514073 0698 5140 73: Cable gland
1088003123 1088 0031 23: Connector
1088003126 1088 0031 26: Connector

1088003128

1088 0031 28: Connector

1088003130 1088 0031 30: Connector
1088003805 1088 0038 05: Pin
1088003806 1088 0038 06: Connector
1088036295 1088 0362 95: Switch

Parts NO.

Name

0697980924 0697 9809 24: Nut
0697981026 0697 9810 26: Plug
0698514075 0698 5140 75: Cable gland
0698514817 0698 5148 17: Insert

0698514833

0698 5148 33: Plug

1088003403 1088 0034 03: Fuse terminal
1088003810 1088 0038 10: Connector
1088005630 1088 0056 30: End bracket
1089050662 1089 0506 62: Terminal

1089903709

1089 9037 09: Fuse link

1089964102 1089 9641 02: Time relay
1624099400 1624 0994 00: Support
1624099200 1624 0992 00: Plate
0147124903 0147 1249 03: Hexagon bolt
0266210000 0266 2100 00: Nut

0301232100

0301 2321 00: Washer

0147132803 0147 1328 03: Hexagon bolt
0266211000 0266 2110 00: Nut
1900221360 1900 2213 60: Cubicle
0017207050 0017 2070 50: Cable

0090140002

0090 1400 02: Mounting rail

0694528528 0694 5285 28: Pin
0694552300 0694 5523 00: Cable lug
0697980921 0697 9809 21: Nut
1624065510 1624 0655 10: Plate

Parts NO.

Name

1900200906 1900 2009 06: Al PCB
1900200912 1900 2009 12: Interface card
1900200905 1900 2009 05: Soldriver PCB
1624072380 1624 0723 80: Cubicle
1624078400 1624 0784 00: Door
1624066800 1624 0668 00: Hinge

1624067300

1624 0673 00: Lock

1202658400 1202 6584 00: Seal
3031233500 3031 2335 00: Washer
3031231800 3031 2318 00: Washer
0266210700 0266 2107 00: Nut
1624099880 1624 0998 80: Copper stub pipe

0301233500

0301 2335 00: Washer

1089049252 1089 0492 52: Pressure transmitter
0661012000 0661 0120 00: Sealing washer
1089948151 1089 9481 51: Transmitter
9740208222 9740 2082 22: Socket
1624088100 1624 0881 00: Pressure switch

0586300034

0586 3000 34: Fitting

1624078700 1624 0787 00: Wire harness
1624079410 1624 0794 10: Decal
1624098800 1624 0988 00: Wire harness
1624099100 1624 0991 00: Wire harness
1625521800 1625 5218 00: Label

For details about our product offerings, pricing, or potential partnerships, our sales team is ready to provide comprehensive information:

  • Our Wechat(Scan below image)
Contact

Parts NO.

Name

1900222005 1900 2220 05: Cubicle (GA 7 380V/50Hz)
1900222001 1900 2220 01: Cubicle (GA 7 400V/50Hz)
1900281204 1900 2812 04: Basis Module
0694528526 0694 5285 26: Fast-on
0697890924 0697 8909 24: Nut
1088001502 1088 0015 02: Connector

1088001536

1088 0015 36: Connector socket

1088003113 1088 0031 13: Connector
1088003118 1088 0031 18: Adaptor
1088003122 1088 0031 22: Connector
1088003123 1088 0031 23: Connector
1088003129 1088 0031 29: Connector
1088003149 1088 0031 49: Connector
1088003152 1088 0031 52: Connector
1088003153 1088 0031 53: Connector

1088003154

1088 0031 54: Connector

1088003156 1088 0031 56: Connector
1088003704 1088 0037 04: Connector
1088003706 1088 0037 06: Connector
1088003730 1088 0037 30: Connector
1088003731 1088 0037 31: Connector
1088003732 1088 0037 32: Connector

1089036251

1089 0362 51: Emergency stop button

1089057758 1089 0577 58: End retainer
1089070002 1089 0700 02: Connector
1089070004 1089 0700 04: Connector socket
1089951151 1089 9511 51: Relay
1089003143 1089 0031 43: Connector
1089933713 1089 9337 13: Contact block
1089951115 1089 9511 15: Socket

1089951157

1089 9511 57: Clip

1900281157 1900 2811 57: Fan Module (1900 2220 01)
1900281456 1900 2814 56: Fan Module (1900 2220 02)
1900281157 1900 2811 57: Fan Module (1900 2220 03)
1900281456 1900 2814 56: Fan Module (1900 2220 05)
1900281157 1900 2811 57: Fan Module (1900 2220 06)
1088001505 1088 0015 05: Connector
1088001536 1088 0015 36: Connector socket
1088003175 1088 0031 75: Connector

1089050660

1089 0506 60: Terminal

1089061201 1089 0612 01: Fuse holder
1089061227 1089 0612 27: Fuse
1089933713 1089 9337 13: Contact block
1089941507 1089 9415 07: Contactor
1089941514 1089 9415 14: Contactor
1900281308 1900 2813 08: Module

1500011800

1500 0118 00: Double faston

1088000420 1088 0004 20: Double faston
1900282207 1900 2822 07: Double faston
1089941514 1089 9415 14: Contactor
1900282204 1900 2822 04: Contactor
1900282207 1900 2822 07: Contactor
1089941526 1089 9415 26: Contactor
1900282204 1900 2822 04: Contactor

1900282207

1900 2822 07: Contactor

1900281324 1900 2813 24: Rail 1X1
1900222003 1900 2220 03: Rail 1X1
1900222007 1900 2220 07: Rail 1X1
1089057758 1089 0577 58: End retainer
1089050604 1089 0506 04: Terminal
0090140002 0090 1400 02: Rail
1900281300 1900 2813 00: Service diagram
9820359825 9820 3598 25: Assembly drawing

1622087348

1622 0873 48: Wire harness

1622259180 1622 2591 80: Plate
9820359816 9820 3598 16: Service diagram
1622108500 1622 1085 00: Cubicle assembly
1622103900 1622 1039 00: Plate
1622107200 1622 1072 00: Plate

1622103780

1622 1037 80: Assembly

1622104500 1622 1045 00: Plate
1622083200 1622 0832 00: Support
0697981030 0697 9810 30: Plug
0697980925 0697 9809 25: Nut

Parts NO.

Name

1079992569 1079 9925 69: Label
1622730200 1622 7302 00: Data-label
1900283002 1900 2830 02: Transfo Module
1900283002 1900 2830 02: Transfo Module
1900283002 1900 2830 02: Transfo Module
1900283008 1900 2830 08: Transfo Module

1900283008

1900 2830 08: Transfo Module

1900283008 1900 2830 08: Transfo Module
1900283008 1900 2830 08: Transfo Module
1900283008 1900 2830 08: Transfo Module
1900283008 1900 2830 08: Transfo Module
1900283008 1900 2830 08: Transfo Module

1089061201

1089 0612 01: Fuse holder

1089061223 1089 0612 23: Fuse
1089943638 1089 9436 38: Transformer
1089943643 1089 9436 43: Transformer
1900283002 1900 2830 02: Transformer
1900283006 1900 2830 06: Transformer
1900282102 1900 2821 02: Starter Module

1900282204

1900 2822 04: Starter Module

1900282101 1900 2821 01: Starter Module
1900282101 1900 2821 01: Starter Module
1900282204 1900 2822 04: Starter Module
1900282204 1900 2822 04: Starter Module
1900282207 1900 2822 07: Starter Module
1900282207 1900 2822 07: Starter Module

1900282207

1900 2822 07: Starter Module

1900282207 1900 2822 07: Starter Module
0090140002 0090 1400 02: Mounting rail
0694528512 0694 5285 12: Isolator cap
0694590010 0694 5900 10: Fork faston
1089057758 1089 0577 58: End retainer
1089070001 1089 0700 01: Connector
1089070003 1089 0700 03: Connector pin

1089941514

1089 9415 14: Contactor

1900282102 1900 2821 02: Contactor
1900282102 1900 2821 02: Contactor
1089941588 1089 9415 88: Supply terminal
1089941588 1089 9415 88: Supply terminal
1089941605 1089 9416 05: Supply terminal
1089941605 1089 9416 05: Supply terminal

1089941605

1089 9416 05: Supply terminal

1089941605 1089 9416 05: Supply terminal
1089941605 1089 9416 05: Supply terminal
1089942417 1089 9424 17: Over load relay
1089942418 1089 9424 18: Over load relay
1089942428 1089 9424 28: Over load relay
1089942429 1089 9424 29: Over load relay

1089942401

1089 9424 01: Over load relay

1089942402 1089 9424 02: Over load relay
1089942404 1089 9424 04: Over load relay
1089942407 1089 9424 07: Over load relay
1089943834 1089 9438 34: Contact block
1089941509 1089 9415 09: Contact block
1900282101 1900 2821 01: Contact block

1900282102

1900 2821 02: Contact block

1900282204

1900 2822 04: Contact block

1900282207 1900 2822 07: Contact block
1089943835 1089 9438 35: Contact block
1089941555 1089 9415 55: Contact block
1900282101 1900 2821 01: Contact block
1900282102 1900 2821 02: Contact block
1900282204 1900 2822 04: Contact block

1900282207

1900 2822 07: Contact block

1089943836 1089 9438 36: Contact block
1900282101 1900 2821 01: Contact block
1900282102 1900 2821 02: Contact block
1089941556 1089 9415 56: Contact block
1089942556 1089 9425 56: Contact block

1900282204

1900 2822 04: Contact block

1900282207 1900 2822 07: Contact block
1622083100 1622 0831 00: Support
0129327033 0129 3270 33: Rivet
1202658400 1202 6584 00: AR Seal

Parts NO.

Name

1613735700 1613 7357 00: CE 11bar(e) 2000 Litres
1613735900 1613 7359 00: CE 11bar(e) 3000 Litres
1613737700 1613 7377 00: CE 16bar(e) 2000 Litres
1613738700 1613 7387 00: CE 16bar(e) 3000 Litres
1613784200 1613 7842 00: MOM 16bar(e) 2000 Litres
1613784300 1613 7843 00: MOM 16bar(e) 3000 Litres
0686371647 0686 3716 47: Plug

0653112800

0653 1128 00: Gasket

0830100796 0830 1007 96: Safety valve 11bar(e)
0830100797 0830 1007 97: Safety valve 16bar(e)
0605412403 0605 4124 03: Reducer
1624084700 1624 0847 00: Plug
0852001014 0852 0010 14: Ball valve
0603513300 0603 5133 00: Nipple

1613727400

1613 7274 00: CE 11bar(e) 250 Litres

1613728400 1613 7284 00: CE 11bar(e) 500 Litres
1613736000 1613 7360 00: CE 16bar(e) 250 Litres
1613736100 1613 7361 00: CE 16bar(e) 500 Litres
1613784500 1613 7845 00: MOM 16bar(e) 250 Litres
1613784700 1613 7847 00: MOM 16bar(e) 500 Litres
0686371603 0686 3716 03: Plug
0605412403 0605 4124 03: Reducer
0830100796 0830 1007 96: Safety valve 11bar(e)

0830100801

0830 1008 01: Safety valve 16bar(e)

0605870084 0605 8700 84: Reducer 250 Litres
0605412403 0605 4124 03: Reducer 500 Litres
1624084700 1624 0847 00: Plug
0852001014 0852 0010 14: Nipple
1613729600 1613 7296 00: CE 11bar(e) 1000 Litres
1613735600 1613 7356 00: CE 11bar(e) 1500 Litres
1613736400 1613 7364 00: CE 16bar(e) 1000 Litres
1613736500 1613 7365 00: CE 16bar(e) 1500 Litres

1613781400

1613 7814 00: MOM 16bar(e) 1000 Litres

1613782900 1613 7829 00: MOM 16bar(e) 1500 Litres
0686371647 0686 3716 47: Plug
0653112800 0653 1128 00: Gasket
0830100796 0830 1007 96: Safety valve 11bar(e) 1000 Litres
0830100797 0830 1007 97: Safety valve 11bar(e) 1500 Litres

0830100801

0830 1008 01: Safety valve 16bar(e) 1000 Litres

0830100802 0830 1008 02: Safety valve 16bar(e) 1500 Litres
0605412403 0605 4124 03: Reducer
1624084700 1624 0847 00: Plug
0852001014 0852 0010 14: Nipple

Parts NO.

Name

0852001032 0852 0010 32: Ball valve
0872100032 0872 1000 32: Manometer
0603410800 0603 4108 00: Nipple
1624087080 1624 0870 80: Copper stub pipe
0586200008 0586 2000 08: Union
0560130503 0560 1305 03: Elbow
0605855200 0605 8552 00: Bushing

0686311548

0686 3115 48: Plug

8102041855

8102 0418 55: EWD 75 115V

8102041822 8102 0418 22: EWD 75 230V
0564330401 0564 3304 01: Tee
0605883205 0605 8832 05: Bushing
0605870070 0605 8700 70: Bushing
0686311548 0686 3115 48: Plug

0603511500

0603 5115 00: Ball valve 250 Litres

0603513100

0603 5131 00: Ball valve 500 Litres

0852001057 0852 0010 57: Ball valve
0872100049 0872 1000 49: Manometer 11bar(e)
0872100050 0872 1000 50: Manometer 16bar(e)
1617712300 1617 7123 00: Coupling
0581202539 0581 2025 39: Tee
0586200008 0586 2000 08: Union
8102043216 8102 0432 16: 115V
8102043208 8102 0432 08: 230V

1624089400

1624 0894 00: Copper stub pipe

0605881406 0605 8814 06: Bushing
0653107000 0653 1070 00: Flat gasket
0560130503 0560 1305 03: Elbow
0603513300 0603 5133 00: Ball valve
0852001032 0852 0010 32: Ball valve
0872100049 0872 1000 49: Manometer
0603410800 0603 4108 00: Nipple

1624087080

1624 0870 80: Copper stub pipe

1617712300 1617 7123 00: Coupling
0581202539 0581 2025 39: Tee
0586200008 0586 2000 08: Union
8102043216 8102 0432 16: 115V
8102043208 8102 0432 08: 230V

0605870070

0605 8700 70: Bushing

0605883205 0605 8832 05: Bushing
0560130503 0560 1305 03: Elbow
0686311503 0686 3115 03: Plug

For details about our product offerings, pricing, or potential partnerships, our sales team is ready to provide comprehensive information:

  • Our Wechat(Scan below image)
Contact

Parts NO.

Name

1616657580 1616 6575 80: Service stage
0147196308 0147 1963 08: Hexagon bolt
1619276600 1619 2766 00: Bolt
0147132503 0147 1325 03: Hexagon bolt
0301233500 0301 2335 00: Washer

0392110012

0392 1100 12: Damper

0301233500 0301 2335 00: Washer
0266211000 0266 2110 00: Nut
1622021101 1622 0211 01: Support
0147132303 0147 1323 03: Hexagon bolt
0303127401 0303 1274 01: Washer
1622025200 1622 0252 00: Support
0301234400 0301 2344 00: Washer

0333323200

0333 3232 00: Lock washer

0147136403 0147 1364 03: Hexagon bolt
0301234400 0301 2344 00: Washer
0211196485 0211 1964 85: Screw
1613986712 1613 9867 12: Grounding
0147196308 0147 1963 08: Hexagon bolt
1622022503 1622 0225 03: Pulley (motor)
1622022504 1622 0225 04: GA 7 10bar(e)

Parts NO.

Name

1622022507 1622 0225 07: GA 7 15psig
1622022404 1622 0224 04: Pulley (element)
1622022407 1622 0224 07: GA 7 10bar(e)
1622022407 1622 0224 07: GA 7 13bar(e)
1622022401 1622 0224 01: GA 7 15psig
1622022405 1622 0224 05: GA 7 175psig

1613903204

1613 9032 04: V-belt set

1613903204 1613 9032 04: GA 5 175psig
1613903202 1613 9032 02: GA 7 10bar(e)
1613903205 1613 9032 05: GA 7 13bar(e)
1613903204 1613 9032 04: GA 7 150psig
1613903203 1613 9032 03: GA 7 175psig

1080418113

1080 4181 13: Motor (GA 7 380V/60Hz)

1080418104 1080 4181 04: Motor (GA 7 400V/50Hz)
0697981028 0697 9810 28: Plug
1622081800 1622 0818 00: Support

1622344600

1622 3446 00: Bolt

1622344603 1622 3446 03: GA 7
1622022505 1622 0225 05: GA 7 175psig
1622022504 1622 0225 04: GA 7 13bar(e)

Parts NO.

Name

0261109940 0261 1099 40: Nut
1622351700 1622 3517 00: Piston
1622352000 1622 3520 00: Tape
1622179705 1622 1797 05: Bushing
0852001021 0852 0010 21: Ball valve
0575012539 0575 0125 39: Hose

0605830099

0605 8300 99: Bushing (10bar(e))

0605830099 0605 8300 99: Bushing (13bar(e))
1608047300 1608 0473 00: Minimum pressure valve
1513053900 1513 0539 00: Housing
1513040201 1513 0402 01: Piston
0661100038 0661 1000 38: Seal
0663210540 0663 2105 40: O-ring
1513006400 1513 0064 00: Spring

1513040101

1513 0401 01: Valve disc

1513006300

1513 0063 00: Spring

1622657601 1622 6576 01: Valve
1624088600 1624 0886 00: Copper stub pipe
0830100997 0830 1009 97: Safety valve (150psig)
0830100997 0830 1009 97: Safety valve (175psig)
0347611300 0347 6113 00: Hose clip
0605870121 0605 8701 21: Bushing
0581120016 0581 1200 16: Coupling

0070600204

0070 6002 04: AR Plastic tube

0661100038

0661 1000 38: Seal washer

0581000034 0581 0000 34: Coupling
0605870036 0605 8700 36: Bushing
0661100039 0661 1000 39: Washer
1613901000 1613 9010 00: Gasket
0147132303 0147 1323 03: Hexagon bolt
0301233500 0301 2335 00: Washer

1503256504

1503 2565 04: Elbow

0571003555 0571 0035 55: Fitting
1622086900 1622 0869 00: Hose
0663313000 0663 3130 00: O-ring
1622023320 1622 0233 20: Coupling
1622351380 1622 3513 80: Unloader assembly

1622351300

1622 3513 00: Housing

1622351401 1622 3514 01: Cover
0335215500 0335 2155 00: Circlip
1622352580 1622 3525 80: Valve
1622351600 1622 3516 00: Rod

Parts NO.

Name

1613900080 1613 9000 80: Air filter assembly
1613900100 1613 9001 00: Air filter element
1089070213 1089 0702 13: Solenoid valve (50Hz)
1089070214 1089 0702 14: Solenoid valve (60Hz)
1089070282 1089 0702 82: Adaptor
0683713600 0683 7136 00: Ring
06160098686 06160 0986 86: O-ring

0301231800

0301 2318 00: Screw

1622369480 1622 3694 80: Blow off valve
0663211155 0663 2111 55: O-ring
1622290600 1622 2906 00: Bushing
1622290500 1622 2905 00: Seal
1622290400 1622 2904 00: Spring
1622290300 1622 2903 00: Spring
1622352200 1622 3522 00: Nozzle
0581000035 0581 0000 35: Coupling

0070600205

0070 6002 05: AR Plastic tube

1619276600 1619 2766 00: Bolt
0830100981 0830 1009 81: Safety valve (10bar(e))
0830101203 0830 1012 03: Safety valve (13bar(e))
1503256613 1503 2566 13: Tee
1613822380 1613 8223 80: WSD 25
0683612800 0683 6128 00: O-ring
0683612400 0683 6124 00: O-ring

0683928900

0683 9289 00: O-ring

0683211128 0683 2111 28: O-ring
0147132203 0147 1322 03: Hexagon bolt
0301232100 0301 2321 00: Washer
1089057554 1089 0575 54: Press.transducer
1079991589 1079 9915 89: Label
1079991598 1079 9915 98: Label
0586100016 0586 1000 16: Coupling

0603410089

0603 4100 89: Nipple

0663312500 0663 3125 00: O-ring
0605870109 0605 8701 09: Bushing
1089057470 1089 0574 70: Temp. sensor
0686371617 0686 3716 17: Plug

0581000077

0581 0000 77: Pipe coupling

0653104600 0653 1046 00: Flat gasket
0581000043 0581 0000 43: Coupling
0582001055 0582 0010 55: Ball valve
0581000055 0581 0000 55: Pipe coupling

Parts NO.

Name

0686371824 0686 3718 24: Plug
0603410203 0603 4102 03: Nipple
0823005009 0823 0050 09: Non return valve
0661100038 0661 1000 38: Seal washer
0663311900 0663 3119 00: O-ring

0571003593

0571 0035 93: Nipple

0575128053 0575 1280 53: Hose assy
0571003592 0571 0035 92: Nipple
0663311600 0663 3116 00: O-ring
0571003594 0571 0035 94: Nipple
1622513000 1622 5130 00: Block

0301234400

0301 2344 00: Washer

0147136503 0147 1365 03: Hexagon bolt
0663210215 0663 2102 15: O-ring
1202899200 1202 8992 00: Plug
1622023500 1622 0235 00: Coupling

1622023600

1622 0236 00: Pipe

1622087100 1622 0871 00: Oil separator
0686371814 0686 3718 14: Plug
1622062400 1622 0624 00: Nipple
1513033701 1513 0337 01: Oilfilter
0663312500 0663 3125 00: O-ring

Parts NO.

Name

0575121656 0575 1216 56: Hose
0575128051 0575 1280 51: Hose
0571003594 0571 0035 94: Nipple
0663312500 0663 3125 00: O-ring
1513016700 1513 0167 00: Sight glass
1622707580 1622 7075 80: Vessel

1622707480

1622 7074 80: ASME

1622707580 1622 7075 80: CE
1622707580 1622 7075 80: LLOYD’S
1079990957 1079 9909 57: Label
0575128101 0575 1281 01: Hose assembly
0571003594 0571 0035 94: Nipple
0663312500 0663 3125 00: O-ring

0663313000

0663 3130 00: O-ring

0663211343 0663 2113 43: O-ring
0571003613 0571 0036 13: Nipple
0147125203 0147 1252 03: Hexagon bolt
0301232100 0301 2321 00: Washer
1622355200 1622 3552 00: Block
0852001045 0852 0010 45: Ball valve
0686371824 0686 3718 24: Plug

For details about our product offerings, pricing, or potential partnerships, our sales team is ready to provide comprehensive information:

  • Our Wechat(Scan below image)
Contact

Parts NO.

Name

1622101400 1622 1014 00: Support
1622081501 1622 0815 01: Support
0147196308 0147 1963 08: Hexagon bolt
1622081600 1622 0816 00: Plate

0129311500

0129 3115 00: Blind rivet

1622059420 1622 0594 20: Aftercooler (GA 7)
0147196308 0147 1963 08: Hexagon bolt
0333322700 0333 3227 00: Lock washer

Parts NO.

Name

1622059407 1622 0594 07: Cooler oil
0147196308 0147 1963 08: Hexagon bolt
1622080190 1622 0801 90: Fan assembly (GA 7)

1622359001

1622 3590 01: Duct

1613980013 1613 9800 13: Fan motor
1613981901 1613 9819 01: Fan
1088130101 1088 1301 01: Cable strip
1088100101 1088 1001 01: Warning mark

Parts NO.

Name

1900222005 1900 2220 05: Cubicle (GA 7 380V/50Hz)
1900222001 1900 2220 01: Cubicle (GA 7 400V/50Hz)
1900281204 1900 2812 04: Basis Module
0694528526 0694 5285 26: Fast-on
0697890924 0697 8909 24: Nut

1088001502

1088 0015 02: Connector

1088001536 1088 0015 36: Connector socket
1088003113 1088 0031 13: Connector
1088003118 1088 0031 18: Adaptor
1088003122 1088 0031 22: Connector

1088003123

1088 0031 23: Connector

1088003129 1088 0031 29: Connector
1088003149 1088 0031 49: Connector
1088003152 1088 0031 52: Connector
1088003153 1088 0031 53: Connector
1088003154 1088 0031 54: Connector
1088003156 1088 0031 56: Connector

1088003704

1088 0037 04: Connector

1088003706 1088 0037 06: Connector
1088003730 1088 0037 30: Connector
1088003731 1088 0037 31: Connector
1088003732 1088 0037 32: Connector
1089036251 1089 0362 51: Emergency stop button

1089057758

1089 0577 58: End retainer

1089070002 1089 0700 02: Connector
1089070004 1089 0700 04: Connector socket
1089951151 1089 9511 51: Relay
1089003143 1089 0031 43: Connector
1089933713 1089 9337 13: Contact block
1089951115 1089 9511 15: Socket

1089951157

1089 9511 57: Clip

1900281157 1900 2811 57: Fan Module (1900 2220 01)
1900281456 1900 2814 56: Fan Module (1900 2220 02)
1900281157 1900 2811 57: Fan Module (1900 2220 03)
1900281456 1900 2814 56: Fan Module (1900 2220 05)
1900281157 1900 2811 57: Fan Module (1900 2220 06)
1088001505 1088 0015 05: Connector

1088001536

1088 0015 36: Connector socket

1088003175 1088 0031 75: Connector
1089050660 1089 0506 60: Terminal
1089061201 1089 0612 01: Fuse holder
1089061227 1089 0612 27: Fuse
1089933713 1089 9337 13: Contact block
1089941507 1089 9415 07: Contactor

1089941514

1089 9415 14: Contactor

1900281308

1900 2813 08: Module

1500011800 1500 0118 00: Double faston
1088000420 1088 0004 20: Double faston
1900282207 1900 2822 07: Double faston
1089941514 1089 9415 14: Contactor
1900282204 1900 2822 04: Contactor

1900282207

1900 2822 07: Contactor

1089941526 1089 9415 26: Contactor
1900282204 1900 2822 04: Contactor
1900282207 1900 2822 07: Contactor
1900281324 1900 2813 24: Rail 1X1
1900222003 1900 2220 03: Rail 1X1
1900222007 1900 2220 07: Rail 1X1

1089057758

1089 0577 58: End retainer

1089050604 1089 0506 04: Terminal
0090140002 0090 1400 02: Rail
1900281300 1900 2813 00: Service diagram
9820359825 9820 3598 25: Assembly drawing
1622087348 1622 0873 48: Wire harness
1622259180 1622 2591 80: Plate

9820359816

9820 3598 16: Service diagram

1622108500 1622 1085 00: Cubicle assembly
1622103900 1622 1039 00: Plate
1622107200 1622 1072 00: Plate
1622103780 1622 1037 80: Assembly
1622104500 1622 1045 00: Plate
1622083200 1622 0832 00: Support
0697981030 0697 9810 30: Plug
0697980925 0697 9809 25: Nut

Parts NO.

Name

1079992569 1079 9925 69: Label
1622730200 1622 7302 00: Data-label
1900283002 1900 2830 02: Transfo Module

1900283002

1900 2830 02: Transfo Module

1900283002 1900 2830 02: Transfo Module
1900283008 1900 2830 08: Transfo Module
1900283008 1900 2830 08: Transfo Module
1900283008 1900 2830 08: Transfo Module
1900283008 1900 2830 08: Transfo Module

1900283008

1900 2830 08: Transfo Module

1900283008 1900 2830 08: Transfo Module
1900283008 1900 2830 08: Transfo Module
1089061201 1089 0612 01: Fuse holder
1089061223 1089 0612 23: Fuse
1089943638 1089 9436 38: Transformer

1089943643

1089 9436 43: Transformer

1900283002 1900 2830 02: Transformer
1900283006 1900 2830 06: Transformer
1900282102 1900 2821 02: Starter Module
1900282204 1900 2822 04: Starter Module

1900282101

1900 2821 01: Starter Module

1900282101 1900 2821 01: Starter Module
1900282204 1900 2822 04: Starter Module
1900282204 1900 2822 04: Starter Module
1900282207 1900 2822 07: Starter Module
1900282207 1900 2822 07: Starter Module

1900282207

1900 2822 07: Starter Module

1900282207

1900 2822 07: Starter Module

0090140002 0090 1400 02: Mounting rail
0694528512 0694 5285 12: Isolator cap
0694590010 0694 5900 10: Fork faston
1089057758 1089 0577 58: End retainer
1089070001 1089 0700 01: Connector

1089070003

1089 0700 03: Connector pin

1089941514 1089 9415 14: Contactor
1900282102 1900 2821 02: Contactor
1900282102 1900 2821 02: Contactor
1089941588 1089 9415 88: Supply terminal
1089941588 1089 9415 88: Supply terminal

1089941605

1089 9416 05: Supply terminal

1089941605 1089 9416 05: Supply terminal
1089941605 1089 9416 05: Supply terminal
1089941605 1089 9416 05: Supply terminal
1089941605 1089 9416 05: Supply terminal

1089942417

1089 9424 17: Over load relay

1089942418 1089 9424 18: Over load relay
1089942428 1089 9424 28: Over load relay
1089942429 1089 9424 29: Over load relay
1089942401 1089 9424 01: Over load relay
1089942402 1089 9424 02: Over load relay

1089942404

1089 9424 04: Over load relay

1089942407 1089 9424 07: Over load relay
1089943834 1089 9438 34: Contact block
1089941509 1089 9415 09: Contact block
1900282101 1900 2821 01: Contact block
1900282102 1900 2821 02: Contact block

1900282204

1900 2822 04: Contact block

1900282207 1900 2822 07: Contact block
1089943835 1089 9438 35: Contact block
1089941555 1089 9415 55: Contact block
1900282101 1900 2821 01: Contact block
1900282102 1900 2821 02: Contact block

1900282204

1900 2822 04: Contact block

1900282207 1900 2822 07: Contact block
1089943836 1089 9438 36: Contact block
1900282101 1900 2821 01: Contact block
1900282102 1900 2821 02: Contact block
1089941556 1089 9415 56: Contact block

1089942556

1089 9425 56: Contact block

1900282204 1900 2822 04: Contact block
1900282207 1900 2822 07: Contact block
1622083100 1622 0831 00: Support
0129327033 0129 3270 33: Rivet
1202658400 1202 6584 00: AR Seal

Parts NO.

Name

2901052600 2901 0526 00 – Filter kit DD 32
2901052700 2901 0527 00 – Filter kit PD 32
2901139900 2901 1399 00: Minimum pressure valve kit

2901074800

2901 0748 00 – Impeller kit WSD

2901091910 2901 0919 10 – Filter / separator kit 8000 hrs
2901056100 2901 0561 00 – Shaft seal kit
2901091920 2901 0919 20: Element mount kit

Parts NO.

Name

2901071200 2901 0712 00 – Drain kit WSD
2901186100 2901 1861 00: Unloading valve kit
2901141100 2901 1411 00: Minimum pressure valve kit

2901170000

2901 1700 00 – Oil can

2901170100 2901 1701 00 – ROTO-XTEND DUTY 5 litres
2901170100 2901 1701 00 – ROTO-XTEND DUTY 20 litres

For details about our product offerings, pricing, or potential partnerships, our sales team is ready to provide comprehensive information:

  • Our Wechat(Scan below image)
Contact

Request a Quote




    For details about our product offerings, pricing, or potential partnerships, our sales team is ready to provide comprehensive information:

    • Room A220,2F, YH Building, Helongyi Road, Helong Street,Baiyun District, Guangzhou, 510440,China

    • +86-20-36293651

    • Mobile/Wechat/Whatsapp: +86 15328879667

    • Our Wechat(Scan below image)

    Contact

    Our dedicated customer support team is available to assist you with any product-related inquiries, technical assistance, or general questions.
