Epiroc COP COP 1838+ Rock Drill, Spare Parts and Overhaul kits
Epiroc COP 1838+ Hydraulic Rock Drill, developed under the Atlas Copco Group’s legacy of innovation, delivers exceptional performance for demanding drilling applications. As a core product of Epiroc—a leading brand spun off from Atlas Copco—the COP 1838+ combines high impact energy, rapid drilling speeds, and durability to optimize productivity in surface and underground mining, quarrying, and construction.
Engineered for precision, this hydraulic rock drill features advanced shock absorption and energy-efficient operation, minimizing wear while maximizing output. To ensure prolonged service life, Epiroc offers dedicated COP 1838+ Spare Parts and Overhaul Kits, meticulously designed to match OEM specifications. These include pistons, seals, rods, and valve systems, enabling seamless maintenance and reducing downtime.
Atlas Copco COP 1838 Spare Parts: ROCK DRILL
Parts NO. |
Name |
| 3115295080 | 3115 2950 80 – FRONT HEAD COMP |
| 3115535080 | 3115 5350 80 – COVER COMPL. |
| 3115234080 | 3115 2340 80 – GEAR HOUSING |
| 3115531380 | 3115 5313 80 – ROT.CHUCK,COMPL |
| 3115527480 | 3115 5274 80 – INTERM. COMPL. |
| 3115527422 | 3115 5274 22 – INTERMED. PART |
| 3115194480 | 3115 1944 80 – CYLINDER |
3115527580 |
3115 5275 80 – SEAL HOUSE COMP |
| 3115277280 | 3115 2772 80 – SEAL HOUSE COMP |
| 3115347380 | 3115 3473 80 – HYDRAULIC MOTOR |
| 3115347381 | 3115 3473 81 – HYDRAULIC MOTOR |
| 3115347383 | 3115 3473 83 – HYDRAULIC MOTOR |
| 3115347385 | 3115 3473 85 – HYDRAULIC MOTOR |
| 3115345181 | 3115 3451 81 – ACCUMULATOR |
| 3115351181 | 3115 3511 81 – ACCUMULATOR |
3115261591 |
3115 2615 91 – RETURN ACCUM. |
| 3115288780 | 3115 2887 80 – CONNECT. PLATE |
| 3115301896 | 3115 3018 96 – CONVERSION KIT |
| 3115301882 | 3115 3018 82 – FRONT PART COMP |
| 3115917090 | 3115 9170 90 – O-RING SET |
| 3115917092 | 3115 9170 92 – SEAL KIT |
| 3115917090 | 3115 9170 90 – O-RING SET |
| 3115923895 | 3115 9238 95 – OVERHAUL KIT |
3115917092 |
3115 9170 92 – SEAL KIT |
| 3115923896 | 3115 9238 96 – OVERHAUL KIT |
| 3115923895 | 3115 9238 95 – OVERHAUL KIT |
| 3115917092 | 3115 9170 92 – SEAL KIT |
| 3115917090 | 3115 9170 90 – O-RING SET |
| 3115923897 | 3115 9238 97 – OVERHAUL KIT |
| 3115923895 | 3115 9238 95 – OVERHAUL KIT |
| 3115917092 | 3115 9170 92 – SEAL KIT |
| 3115917090 | 3115 9170 90 – O-RING SET |
3115212380 |
3115 2123 80 – STOP RING |
| 3115561690 | 3115 5616 90 – CONVERSION KIT |
| 3115917090 | 3115 9170 90 – O-RING SET |
| 3115535080 | 3115 5350 80 – COVER COMPL. |
| 3115531390 | 3115 5313 90 – CONVERSION KIT |
Parts NO. |
Name |
| 3115531380 | 3115 5313 80 – ROT.CHUCK,COMPL |
| 3115527480 | 3115 5274 80 – INTERM. COMPL. |
| 3115527422 | 3115 5274 22 – INTERMED. PART |
| 3115527580 | 3115 5275 80 – SEAL HOUSE COMP |
| 3115295080 | 3115 2950 80 – FRONT HEAD COMP COVER GROUP |
| 7490516087 | 7490 5160 87 – SHANK ADAPTER |
| 7490516088 | 7490 5160 88 – SHANK ADAPTER |
7490516098 |
7490 5160 98 – SHANK ADAPTER |
| 7490516099 | 7490 5160 99 – SHANK ADAPTER |
| 7490516120 | 7490 5161 20 – SHANK ADAPTER |
| 7490516121 | 7490 5161 21 – SHANK ADAPTER |
| 7490516158 | 7490 5161 58 – SHANK ADAPTER |
| 7490516184 | 7490 5161 84 – SHANK ADAPTER |
| 7490516206 | 7490 5162 06 – SHANK ADAPTER |
| 7490516342 | 7490 5163 42 – SHANK ADAPTER |
3115223100 |
3115 2231 00 – DRILL COLLAR |
| 3115028600 | 3115 0286 00 – DOME NUT WASHER |
| 3115028700 | 3115 0287 00 – HYDRAULIC MOTOR |
| 3115347380 | 3115 3473 80 – HYDRAULIC MOTOR |
| 3115347381 | 3115 3473 81 – HYDRAULIC MOTOR |
| 3115347383 | 3115 3473 83 – HYDRAULIC MOTOR |
| 3115347385 | 3115 3473 85 – HYDRAULIC MOTOR |
| 3115027700 | 3115 0277 00 – COUPLING CIRCLIP |
0335213000 |
0335 2130 00 – GASKET |
| 3115032700 | 3115 0327 00 – NUT ACCUMULATOR |
| 3115354800 | 3115 3548 00 – ACCUMULATOR RETURN ACCUM. LABEL |
| 3115345181 | 3115 3451 81 – NIPPLE |
| 3115351181 | 3115 3511 81 – NIPPLE |
| 3115261591 | 3115 2615 91 – PLUG |
| 3115573700 | 3115 5737 00 – PLUG |
| 3115575701 | 3115 5757 01 – PLUG |
| 3176651200 | 3176 6512 00 – PLUG |
| 3176651400 | 3176 6514 00 – PLUG |
| 0686925026 | 0686 9250 26 – PLUG |
| 0686925027 | 0686 9250 27 – PLUG |
| 3115160391 | 3115 1603 91 – NIPPLE SET |
Atlas Copco COP 1838 Spare Parts: FRONT HEAD COMP
Parts NO. |
Name |
| 3115295000 | 3115 2950 00 – FRONT PART |
| 3115211800 | 3115 2118 00 – GUIDE |
| 3115212000 | 3115 2120 00 – FLUSHING HEAD |
| 3115233300 | 3115 2333 00 – CUP SEAL |
3115519000 |
3115 5190 00 – CUP SEAL |
| 3115515200 | 3115 5152 00 – CONNECT. PLATE |
| 0665100012 | 0665 1000 12 – SEAL |
| 0147140103 | 0147 1401 03 – SCREW, HEX HEAD |
Parts NO. |
Name |
| 3315019508 | 3315 0195 08 – LOCK WASHER |
| 3115324500 | 3115 3245 00 – SEAL RING |
| 3115212200 | 3115 2122 00 – STOP RING |
| 0663214501 | 0663 2145 01 – O-RING |
0663214501 |
0663 2145 01 – O-RING |
| 0663214501 | 0663 2145 01 – O-RING |
| 0663214501 | 0663 2145 01 – O-RING |
| 0663214300 | 0663 2143 00 – O-RING |
Atlas Copco COP 1838 Spare Parts: COVER GROUP
Parts NO. |
Name |
| 3115535080 | 3115 5350 80 – COVER COMPL. |
| 0663615100 | 0663 6151 00 – O-RING |
| 3115324500 | 3115 3245 00 – SEAL RING |
Parts NO. |
Name |
| 3115534700 | 3115 5347 00 – SIDE BOLT |
| 0102047300 | 0102 0473 00 – PIN |
Atlas Copco COP 1838 Spare Parts: COVER COMPL.
Parts NO. |
Name |
| 0666719001 | 0666 7190 01 – RADIAL LIP SEAL |
| 0335217300 | 0335 2173 00 – CIRCLIP |
Parts NO. |
Name |
| 0686371606 | 0686 3716 06 – PLUG |
| 0661102600 | 0661 1026 00 – SEAL WASHER |
Atlas Copco COP1838 Spare Parts: GEAR HOUSING GR
Parts NO. |
Name |
| 3115234080 | 3115 2340 80 – GEAR HOUSING |
| 3115082100 | 3115 0821 00 – SHAFT |
| 0516150401 | 0516 1504 01 – NEEDLE BEARING |
| 3115082300 | 3115 0823 00 – WASHER |
| 3115027400 | 3115 0274 00 – GEAR WHEEL |
0516153800 |
0516 1538 00 – NEEDLE BEARING |
| 3115082400 | 3115 0824 00 – SLEEVE |
| 0667120600 | 0667 1206 00 – SEAL |
| 3115274200 | 3115 2742 00 – GUIDE SLEEVE |
| 0663213301 | 0663 2133 01 – O-RING |
| 3115531380 | 3115 5313 80 – ROT.CHUCK,COMPL |
Parts NO. |
Name |
| 0509022100 | 0509 0221 00 – ROLLER BEARING |
| 0509022300 | 0509 0223 00 – ROLLER BEARING |
| 3115029701 | 3115 0297 01 – SHIM |
| 3115029702 | 3115 0297 02 – SHIM |
| 3115029703 | 3115 0297 03 – SHIM |
3115531400 |
3115 5314 00 – DRIVER |
| 3115296801 | 3115 2968 01 – ROT.CH.BUSHING |
| 3115145700 | 3115 1457 00 – SIDE BOLT |
| 3115324500 | 3115 3245 00 – SEAL RING |
| 0663212000 | 0663 2120 00 – O-RING |
Atlas Copco COP1838 Spare Parts: GEAR HOUSING
Parts NO. |
Name |
| 0544216200 | 0544 2162 00 – GREASE NIPPLE |
| 0686420103 | 0686 4201 03 – PLUG |
| 0653903800 | 0653 9038 00 – GASKET |
Parts NO. |
Name |
| 0666718801 | 0666 7188 01 – RADIAL LIP SEAL |
| 0335216900 | 0335 2169 00 – CIRCLIP |
| 3115027300 | 3115 0273 00 – WASHER |
For details about our product offerings, pricing, or potential partnerships, our sales team is ready to provide comprehensive information:
Atlas Copco COP1838 Spare Parts: ROT.CHUCK,COMPL
Parts NO. |
Name |
| 3115188100 | 3115 1881 00 – BUSHING |
Parts NO. |
Name |
| 3115188100 | 3115 1881 00 – BUSHING |
Atlas Copco COP1838 Spare Parts: INTERM.PART GRP
Parts NO. |
Name |
| 3115527480 | 3115 5274 80 – INTERM. COMPL. |
| 3115238400 | 3115 2384 00 – VALVE SEAT |
| 3115238300 | 3115 2383 00 – VALVE CONE |
| 3115329018 | 3115 3290 18 – SEAL RING |
| 3115345500 | 3115 3455 00 – CONNECT. PLATE |
| 0211196084 | 0211 1960 84 – SCREW |
| 0663210062 | 0663 2100 62 – O-RING |
Parts NO. |
Name |
| 3115298800 | 3115 2988 00 – SEAL RING |
| 3115514601 | 3115 5146 01 – SEAL RING |
| 3115187900 | 3115 1879 00 – SEAL KIT |
| 3115188000 | 3115 1880 00 – SEAL KIT |
| 3115297100 | 3115 2971 00 – DAMPING PISTON |
| 0686911000 | 0686 9110 00 – PROTECTION PLUG |
Atlas Copco COP1838 Spare Parts: INTERM. COMPL.
Parts NO. |
Name |
| 3115527422 | 3115 5274 22 – INTERMED. PART |
| 3115535802 | 3115 5358 02 – LINER |
| 3115328923 | 3115 3289 23 – SEAL RING |
Parts NO. |
Name |
| 3115328913 | 3115 3289 13 – SEAL RING |
| 3115536000 | 3115 5360 00 – DISK SPRING |
| 3115174606 | 3115 1746 06 – NOZZLE |
Atlas Copco COP1838 Spare Parts: CYLINDER GROUP
Parts NO. |
Name |
| 3115194480 | 3115 1944 80 – CYLINDER |
| 3115527580 | 3115 5275 80 – SEAL HOUSE COMP |
| 3115167100 | 3115 1671 00 – PISTON GUIDE |
| 3115212900 | 3115 2129 00 – PISTON |
3115168000 |
3115 1680 00 – PISTON GUIDE |
| 3115277280 | 3115 2772 80 – SEAL HOUSE COMP |
| 3115176500 | 3115 1765 00 – VALVE PISTON |
| 3115207703 | 3115 2077 03 – VALVE COVER |
| 3115207605 | 3115 2076 05 – VALVE COVER |
Parts NO. |
Name |
| 0147143803 | 0147 1438 03 – SCREW, HEX HEAD |
| 3115329100 | 3115 3291 00 – REG. PLUG |
| 3115321400 | 3115 3214 00 – NUT |
| 3115169700 | 3115 1697 00 – SEAL WASHER |
3115324500 |
3115 3245 00 – SEAL RING |
| 0663613401 | 0663 6134 01 – O-RING |
| 0663613401 | 0663 6134 01 – O-RING |
| 0663213301 | 0663 2133 01 – O-RING |
| 0663213301 | 0663 2133 01 – O-RING |
Atlas Copco COP1838 Spare Parts: CYLINDER
Parts NO. |
Name |
| 3115116500 | 3115 1165 00 – STUD |
| 3115211200 | 3115 2112 00 – GUIDE |
| 0259031100 | 0259 0311 00 – THREAD INSERT |
| 0259001100 | 0259 0011 00 – THREAD INSERT |
Parts NO. |
Name |
| 0259206100 | 0259 2061 00 – THREAD INSERT |
| 3115182500 | 3115 1825 00 – PLUG |
| 0686644704 | 0686 6447 04 – PLUG |
| 0661103400 | 0661 1034 00 – SEAL WASHER |
Atlas Copco COP1838 Spare Parts: SEAL HOUSE COMP
Parts NO. |
Name |
| 3115097000 | 3115 0970 00 – SEAL KIT |
| 0663210576 | 0663 2105 76 – O-RING |
Parts NO. |
Name |
| 3115115600 | 3115 1156 00 – SEAL KIT |
| 0663613500 | 0663 6135 00 – O-RING |
Atlas Copco COP1838 Spare Parts: BACK HEAD GROUP
Parts NO. |
Name |
| 3115348100 | 3115 3481 00 – BACK HEAD |
| 0147148103 | 0147 1481 03 – SCREW, HEX HEAD |
Parts NO. |
Name |
| 0663613800 | 0663 6138 00 – O-RING |
Atlas Copco COP1838 Spare Parts: HYDRAULIC MOTOR
Parts NO. |
Name |
| 3115347390 | 3115 3473 90 – SEAL KIT |
Parts NO. |
Name |
| 3115 3473 90 | 3115347390 – SEAL KIT |
Atlas Copco COP1838 Spare Parts: ACCUMULATOR
Parts NO. |
Name |
| 3115187000 | 3115 1870 00 – PROTECTION PLUG |
| 3115182201 | 3115 1822 01 – DIAPHRAGM |
| 3115376800 | 3115 3768 00 – VALVE |
| 3115026300 | 3115 0263 00 – PLUG |
Parts NO. |
Name |
| 0663612100 | 0663 6121 00 – O-RING |
| 3115271590 | 3115 2715 90 – LABEL SET |
| 3115270210 | 3115 2702 10 – SCREW |
| 3115271490 | 3115 2714 90 – LABEL SET |
Atlas Copco COP1838 Spare Parts: RETURN ACCUM.
Parts NO. |
Name |
| 0686901054 | 0686 9010 54 – PROTECTING PLUG |
Parts NO. |
Name |
| 3115227580 | 3115 2275 80 – HOLDER SET |
For details about our product offerings, pricing, or potential partnerships, our sales team is ready to provide comprehensive information:
Atlas Copco COP1838 Spare Parts: OPTIONAL SET
Parts NO. |
Name |
| 3115026200 | 3115 0262 00 – VALVE |
| 3115219681 | 3115 2196 81 – TEST VALVE |
| 3115028400 | 3115 0284 00 – WASHER |
| 3115216300 | 3115 2163 00 – MANDREL |
| 3115272480 | 3115 2724 80 – DISASSEMB.TOOLS |
0371110002 |
0371 1100 02 – LIFTING EYE |
| 3115251900 | 3115 2519 00 – TIGHTENING TOOL |
| 3115288780 | 3115 2887 80 – CONNECT.PLATE |
| 3115363501 | 3115 3635 01 – PISTON |
| 3115303100 | 3115 3031 00 – GUIDE |
| 3115323000 | 3115 3230 00 – GROUTING UNIT |
| 7403091401 | 7403 0914 01 – SHANK ADAPTER |
Parts NO. |
Name |
| 7404091401 | 7404 0914 01 – SHANK ADAPTER |
| 3115301896 | 3115 3018 96 – CONVERSION KIT |
| 3115347800 | 3115 3478 00 – PLATE |
| 3115347900 | 3115 3479 00 – PLATE |
| 3115347390 | 3115 3473 90 – SEAL KIT |
3115917090 |
3115 9170 90 – O-RING SET |
| 3115917092 | 3115 9170 92 – SEAL KIT |
| 3115923895 | 3115 9238 95 – OVERHAUL KIT |
| 3115923896 | 3115 9238 96 – OVERHAUL KIT |
| 3115923897 | 3115 9238 97 – OVERHAUL KIT |
| 3115561690 | 3115 5616 90 – CONVERSION KIT |
Atlas Copco COP1838 Spare Parts: CONNECT. PLATE
Parts NO. |
Name |
| 0663210062 | 0663 2100 62 – O-RING |
| 3115288800 | 3115 2888 00 – PRESSURE SCREW |
Parts NO. |
Name |
| 0663210936 | 0663 2109 36 – O-RING |
Atlas Copco COP1838 Spare Parts: CONVERSION KIT
Parts NO. |
Name |
| 3115301882 | 3115 3018 82 – FRONT PART COMP |
Parts NO. |
Name |
| 3115572400 | 3115 5724 00 – SIDE BOLT |
Atlas Copco COP1838 Spare Parts: FRONT PART COMP
Parts NO. |
Name |
| 3115301810 | 3115 3018 10 – FRONT PART |
| 3115301901 | 3115 3019 01 – GUIDE |
| 3115302400 | 3115 3024 00 – WIPER |
3115302201 |
3115 3022 01 – FLUSHING HEAD |
| 3115233300 | 3115 2333 00 – CUP SEAL |
| 3115302101 | 3115 3021 01 – SPACER |
| 0102048200 | 0102 0482 00 – PIN |
Parts NO. |
Name |
| 3115324500 | 3115 3245 00 – SEAL RING |
| 3115302001 | 3115 3020 01 – STOP RING |
| 0663214300 | 0663 2143 00 – O-RING |
| 0663214300 | 0663 2143 00 – O-RING |
| 0663214300 | 0663 2143 00 – O-RING |
| 0663214300 | 0663 2143 00 – O-RING |
Atlas Copco COP1838 Spare Parts: O-RING SET
Parts NO. |
Name |
| 0663210062 | 0663 2100 62 – O-RING |
| 0663210576 | 0663 2105 76 – O-RING |
| 0663210596 | 0663 2105 96 – O-RING |
0663210937 |
0663 2109 37 – O-RING |
| 0663211000 | 0663 2110 00 – O-RING |
| 0663211500 | 0663 2115 00 – O-RING |
| 0663212000 | 0663 2120 00 – O-RING |
| 0663212800 | 0663 2128 00 – O-RING |
| 0663212901 | 0663 2129 01 – O-RING |
| 0663213301 | 0663 2133 01 – O-RING |
0663213400 |
0663 2134 00 – O-RING |
| 0663214300 | 0663 2143 00 – O-RING |
| 0663214400 | 0663 2144 00 – O-RING |
| 0663214501 | 0663 2145 01 – O-RING |
| 0663612100 | 0663 6121 00 – O-RING |
| 0663613401 | 0663 6134 01 – O-RING |
| 0663613500 | 0663 6135 00 – O-RING |
Parts NO. |
Name |
| 0663613501 | 0663 6135 01 – O-RING |
| 0663613800 | 0663 6138 00 – O-RING |
| 0663614300 | 0663 6143 00 – O-RING |
| 0663614400 | 0663 6144 00 – O-RING |
| 0663615100 | 0663 6151 00 – O-RING |
| 0663905600 | 0663 9056 00 – O-RING |
0663910401 |
0663 9104 01 – O-RING |
| 0663915800 | 0663 9158 00 – O-RING |
| 3115298800 | 3115 2988 00 – SEAL RING |
| 3115324500 | 3115 3245 00 – SEAL RING |
| 3115328913 | 3115 3289 13 – SEAL RING |
| 3115328917 | 3115 3289 17 – SEAL RING |
3115328923 |
3115 3289 23 – SEAL RING |
| 3115329018 | 3115 3290 18 – SEAL RING |
| 3115514601 | 3115 5146 01 – SEAL RING |
| 9125619100 | 9125 6191 00 – O-RING |
| 9900000300 | 9900 0003 00 – PLASTIC BAG |
Atlas Copco COP1838 Spare Parts: SEAL KIT
Parts NO. |
Name |
| 3115917090 | 3115 9170 90 – O-RING SET |
| 3115032700 | 3115 0327 00 – GASKET |
| 0661103800 | 0661 1038 00 – SEAL WASHER |
| 0663210937 | 0663 2109 37 – O-RING |
| 0663212800 | 0663 2128 00 – O-RING |
| 9125619100 | 9125 6191 00 – O-RING |
3115233300 |
3115 2333 00 – CUP SEAL |
| 3115238600 | 3115 2386 00 – CUP SEAL |
| 3115269300 | 3115 2693 00 – CUP SEAL |
| 3115519000 | 3115 5190 00 – CUP SEAL |
| 0665100012 | 0665 1000 12 – SEAL |
| 0666719001 | 0666 7190 01 – RADIAL LIP SEAL |
Parts NO. |
Name |
| 0544216200 | 0544 2162 00 – GREASE NIPPLE PLUG |
| 0686420103 | 0686 4201 03 – GASKET |
| 0653903800 | 0653 9038 00 – RADIAL LIP SEAL |
| 0666718801 | 0666 7188 01 – SEAL |
| 0667120600 | 0667 1206 00 – SEAL WASHER |
0661102000 |
0661 1020 00 – SEAL KIT |
| 3115188090 | 3115 1880 90 – SEAL WASHER |
| 0661103400 | 0661 1034 00 – SEAL KIT |
| 3115097000 | 3115 0970 00 – SEAL KIT |
| 3115115600 | 3115 1156 00 – SEAL KIT |
| 3115169700 | 3115 1697 00 – SEAL WASHER |
Atlas Copco COP1838 Spare Parts: OVERHAUL KIT
Parts NO. |
Name |
| 3115917092 | 3115 9170 92 – SEAL KIT |
| 3115028600 | 3115 0286 00 – DOME NUT |
| 3115028700 | 3115 0287 00 – WASHER |
| 0335213000 | 0335 2130 00 – CIRCLIP |
| 3115354800 | 3115 3548 00 – NUT |
| 3115182201 | 3115 1822 01 – DIAPHRAGM |
| 3115270210 | 3115 2702 10 – SCREW |
3115271490 |
3115 2714 90 – LABEL SET |
| 3115376800 | 3115 3768 00 – VALVE |
| 3115274590 | 3115 2745 90 – LABEL SET |
| 3115192602 | 3115 1926 02 – DIAPHRAGM |
| 3115261710 | 3115 2617 10 – PLUG |
| 3115316400 | 3115 3164 00 – LABEL |
| 3115575701 | 3115 5757 01 – LABEL |
3147140103 |
3147 1401 03 – SCREW, HEX HEAD |
| 0335217300 | 0335 2173 00 – CIRCLIP |
| 3115534700 | 3115 5347 00 – SIDE BOLT |
| 0516150401 | 0516 1504 01 – NEEDLE BEARING |
| 0516153800 | 0516 1538 00 – NEEDLE BEARING |
| 0509022100 | 0509 0221 00 – ROLLER BEARING |
| 0509022300 | 0509 0223 00 – ROLLER BEARING |
3115029701 |
3115 0297 01 – SHIM |
| 3115029702 | 3115 0297 02 – SHIM |
| 3115029703 | 3115 0297 03 – SHIM |
Parts NO. |
Name |
| 3115145700 | 3115 1457 00 – SIDE BOLT |
| 0211196084 | 0211 1960 84 – SCREW |
| 0147143803 | 0147 1438 03 – SCREW, HEX HEAD |
| 0147148103 | 0147 1481 03 – SCREW, HEX HEAD |
| 3115923895 | 3115 9238 95 – OVERHAUL KIT GUIDE |
3115211800 |
3115 2118 00 – STOP RING DRIVER |
| 3115521200 | 3115 5212 00 – ROT.CH.BUSHING LINER |
| 3115531400 | 3115 5314 00 – DISK SPRING DAMPING PISTON |
| 3115536000 | 3115 5360 00 – PISTON GUIDE |
| 3115537600 | 3115 5376 00 – PISTON GUIDE |
| 3115527100 | 3115 5271 00 – PISTON GUIDE |
3115167100 |
3115 1671 00 – PISTON GUIDE |
| 3115363501 | 3115 3635 01 – PISTON GUIDE |
| 3115168000 | 3115 1680 00 – PISTON GUIDE |
| 3115923895 | 3115 9238 95 – OVERHAUL KIT |
| 3115211900 | 3115 2119 00 – GUIDE |
| 3115212380 | 3115 2123 80 – STOP RING |
3115531400 |
3115 5314 00 – DRIVER |
| 3115296801 | 3115 2968 01 – ROT.CH.BUSHING |
| 3115535802 | 3115 5358 02 – LINER |
| 3115536000 | 3115 5360 00 – DISK SPRING |
| 3115297100 | 3115 2971 00 – DAMPING PISTON |
| 3115363501 | 3115 3635 01 – PISTON |
| 0335216900 | 0335 2169 00 – CIRCLIP |
For details about our product offerings, pricing, or potential partnerships, our sales team is ready to provide comprehensive information:
Atlas Copco COP1838 Spare Parts: STOP RING
Parts NO. |
Name |
| 0663210596 | 0663 2105 96 – O-RING |
Parts NO. |
Name |
| 0663210596 | 0663 2105 96 – O-RING |
Atlas Copco COP1838 Spare Parts: CONVERSION KIT
Parts NO. |
Name |
| 3115029790 | 3115 0297 90 – SHIMS SET |
| 3115531380 | 3115 5313 80 – ROT.CHUCK,COMPL |
| 0509022100 | 0509 0221 00 – ROLLER BEARING |
| 0509022300 | 0509 0223 00 – ROLLER BEARING |
| 3115531400 | 3115 5314 00 – DRIVER |
Parts NO. |
Name |
| 3115188090 | 3115 1880 90 – SEAL KIT |
| 3115917090 | 3115 9170 90 – O-RING SET |
| 3115531390 | 3115 5313 90 – CONVERSION KIT |
| 3115527480 | 3115 5274 80 – INTERM. COMPL. |
| 3115527580 | 3115 5275 80 – SEAL HOUSE COMP |
Atlas Copco COP1838 Spare Parts: CROSS REFERENCE LIST
Parts NO. |
Name |
| 0102047300 | 0102 0473 00 – PIN |
| 0102048200 | 0102 0482 00 – PIN |
| 0147140103 | 0147 1401 03 – SCREW, HEX HEAD |
| 0147143803 | 0147 1438 03 – SCREW, HEX HEAD |
| 0147148103 | 0147 1481 03 – SCREW, HEX HEAD |
| 0211196084 | 0211 1960 84 – SCREW |
0259001100 |
0259 0011 00 – THREAD INSERT |
| 0259006800 | 0259 0068 00 – THREAD INSERT |
| 0259031100 | 0259 0311 00 – THREAD INSERT |
| 0259206100 | 0259 2061 00 – THREAD INSERT |
| 0335213000 | 0335 2130 00 – CIRCLIP |
| 0335216900 | 0335 2169 00 – CIRCLIP |
| 0335217300 | 0335 2173 00 – CIRCLIP |
0371110002 |
0371 1100 02 – LIFTING EYE |
| 0509022100 | 0509 0221 00 – ROLLER BEARING |
| 0509022300 | 0509 0223 00 – ROLLER BEARING |
| 0516150401 | 0516 1504 01 – NEEDLE BEARING |
| 0516153800 | 0516 1538 00 – NEEDLE BEARING |
| 0544216200 | 0544 2162 00 – GREASE NIPPLE |
| 0653903800 | 0653 9038 00 – GASKET |
| 0661102000 | 0661 1020 00 – SEAL WASHER |
0661102600 |
0661 1026 00 – SEAL WASHER |
| 0661103400 | 0661 1034 00 – SEAL WASHER |
| 0661103800 | 0661 1038 00 – SEAL WASHER |
| 0663210062 | 0663 2100 62 – O-RING |
| 0663210576 | 0663 2105 76 – O-RING |
| 0663210596 | 0663 2105 96 – O-RING |
| 0663210936 | 0663 2109 36 – O-RING |
| 0663614400 | 0663 6144 00 – O-RING |
0663615100 |
0663 6151 00 – O-RING |
| 0663905600 | 0663 9056 00 – O-RING |
| 0663910401 | 0663 9104 01 – O-RING |
| 0663915800 | 0663 9158 00 – O-RING |
| 0665100012 | 0665 1000 12 – SEAL |
| 0666718801 | 0666 7188 01 – RADIAL LIP SEAL |
| 0666719001 | 0666 7190 01 – RADIAL LIP SEAL |
0667120600 |
0667 1206 00 – SEAL |
| 0686371606 | 0686 3716 06 – PLUG |
| 0686420103 | 0686 4201 03 – PLUG |
| 0686644200 | 0686 6442 00 – PLUG |
| 0686644704 | 0686 6447 04 – PLUG |
| 0686901054 | 0686 9010 54 – PROTECTING PLUG |
| 0686911000 | 0686 9110 00 – PROTECTION PLUG |
| 0686925026 | 0686 9250 26 – PLUG |
0686925027 |
0686 9250 27 – PLUG |
| 3115026200 | 3115 0262 00 – VALVE |
| 3115026300 | 3115 0263 00 – PLUG |
| 3115027300 | 3115 0273 00 – WASHER |
| 3115027400 | 3115 0274 00 – GEAR WHEEL |
| 3115027700 | 3115 0277 00 – COUPLING |
| 3115028400 | 3115 0284 00 – WASHER |
| 3115028600 | 3115 0286 00 – DOME NUT |
| 3115028700 | 3115 0287 00 – WASHER |
3115029701 |
3115 0297 01 – SHIM |
| 3115029702 | 3115 0297 02 – SHIM |
| 0663210937 | 0663 2109 37 – O-RING |
| 0663211000 | 0663 2110 00 – O-RING |
| 0663211500 | 0663 2115 00 – O-RING |
| 0663212000 | 0663 2120 00 – O-RING |
| 0663212800 | 0663 2128 00 – O-RING |
| 0663212901 | 0663 2129 01 – O-RING |
0663213301 |
0663 2133 01 – O-RING |
| 0663213400 | 0663 2134 00 – O-RING |
| 0663214300 | 0663 2143 00 – O-RING |
| 0663214400 | 0663 2144 00 – O-RING |
| 0663214501 | 0663 2145 01 – O-RING |
| 0663612100 | 0663 6121 00 – O-RING |
| 0663613401 | 0663 6134 01 – O-RING |
| 0663613500 | 0663 6135 00 – O-RING |
0663613501 |
0663 6135 01 – O-RING |
0663613800 |
0663 6138 00 – O-RING |
| 0663614300 | 0663 6143 00 – O-RING |
| 3115029703 | 3115 0297 03 – SHIM |
| 3115029790 | 3115 0297 90 – SHIMS SET |
| 3115032700 | 3115 0327 00 – GASKET |
| 3115082100 | 3115 0821 00 – SHAFT |
| 3115082300 | 3115 0823 00 – WASHER |
| 3115082400 | 3115 0824 00 – SLEEVE |
| 3115097000 | 3115 0970 00 – SEAL KIT |
3115115600 |
3115 1156 00 – SEAL KIT |
| 3115116500 | 3115 1165 00 – STUD |
| 3115145700 | 3115 1457 00 – SIDE BOLT |
| 3115160391 | 3115 1603 91 – NIPPLE SET |
| 3115167100 | 3115 1671 00 – PISTON GUIDE |
| 3115168000 | 3115 1680 00 – PISTON GUIDE |
| 3115169700 | 3115 1697 00 – SEAL WASHER |
| 3115174606 | 3115 1746 06 – NOZZLE |
| 3115176500 | 3115 1765 00 – VALVE PISTON |
| 3115182201 | 3115 1822 01 – DIAPHRAGM |
3115182500 |
3115 1825 00 – PLUG |
| 3115187000 | 3115 1870 00 – PROTECTION PLUG |
| 3115187900 | 3115 1879 00 – SEAL KIT |
| 3115188000 | 3115 1880 00 – SEAL KIT |
| 3115188090 | 3115 1880 90 – SEAL KIT |
| 3115188100 | 3115 1881 00 – BUSHING |
| 3115192602 | 3115 1926 02 – DIAPHRAGM |
3115194480 |
3115 1944 80 – CYLINDER |
| 3115207605 | 3115 2076 05 – VALVE COVER |
| 3115207703 | 3115 2077 03 – VALVE COVER |
| 3115211200 | 3115 2112 00 – GUIDE |
| 3115211800 | 3115 2118 00 – GUIDE |
| 3115211900 | 3115 2119 00 – GUIDE |
Parts NO. |
Name |
| 3115227580 | 3115 2275 80 – HOLDER SET |
| 3115233300 | 3115 2333 00 – CUP SEAL |
| 3115234080 | 3115 2340 80 – GEAR HOUSING |
| 3115238300 | 3115 2383 00 – VALVE CONE |
| 3115238400 | 3115 2384 00 – VALVE SEAT |
| 3115238600 | 3115 2386 00 – CUP SEAL |
3115240100 |
3115 2401 00 – PLUG |
| 3115251900 | 3115 2519 00 – TIGHTENING TOOL |
| 3115261591 | 3115 2615 91 – RETURN ACCUM. |
| 3115261710 | 3115 2617 10 – PLUG |
| 3115269300 | 3115 2693 00 – CUP SEAL |
| 3115270210 | 3115 2702 10 – SCREW |
| 3115271490 | 3115 2714 90 – LABEL SET |
3115271590 |
3115 2715 90 – LABEL SET |
| 3115272480 | 3115 2724 80 – DISASSEMB.TOOLS |
| 3115274200 | 3115 2742 00 – GUIDE SLEEVE |
| 3115277280 | 3115 2772 80 – SEAL HOUSE COMP |
| 3115288780 | 3115 2887 80 – CONNECT. PLATE |
| 3115288800 | 3115 2888 00 – PRESSURE SCREW |
| 3115295000 | 3115 2950 00 – FRONT PART |
| 3115295080 | 3115 2950 80 – FRONT HEAD COMP |
| 3115296801 | 3115 2968 01 – ROT.CH.BUSHING |
3115297100 |
3115 2971 00 – DAMPING PISTON |
| 3115298800 | 3115 2988 00 – SEAL RING |
| 3115301810 | 3115 3018 10 – FRONT PART |
| 3115301882 | 3115 3018 82 – FRONT PART COMP |
| 3115301896 | 3115 3018 96 – CONVERSION KIT |
| 3115301901 | 3115 3019 01 – GUIDE |
| 3115302001 | 3115 3020 01 – STOP RING |
| 3115302101 | 3115 3021 01 – SPACER |
| 3115302201 | 3115 3022 01 – FLUSHING HEAD |
3115302400 |
3115 3024 00 – WIPER |
| 3115303100 | 3115 3031 00 – GUIDE |
| 3115316400 | 3115 3164 00 – LABEL |
| 3115321400 | 3115 3214 00 – NUT |
| 3115323000 | 3115 3230 00 – GROUTING UNIT |
3115324500 |
3115 3245 00 – SEAL RING |
| 3115328913 | 3115 3289 13 – SEAL RING |
| 3115328917 | 3115 3289 17 – SEAL RING |
| 3115328923 | 3115 3289 23 – SEAL RING |
| 3115329018 | 3115 3290 18 – SEAL RING |
| 3115329100 | 3115 3291 00 – REG. PLUG |
3115345181 |
3115 3451 81 – ACCUMULATOR |
| 3115345500 | 3115 3455 00 – CONNECT. PLATE |
| 3115347380 | 3115 3473 80 – HYDRAULIC MOTOR |
| 3115347381 | 3115 3473 81 – HYDRAULIC MOTOR |
| 3115347383 | 3115 3473 83 – HYDRAULIC MOTOR |
| 3115347385 | 3115 3473 85 – HYDRAULIC MOTOR |
| 3115347390 | 3115 3473 90 – SEAL KIT |
| 3115347900 | 3115 3479 00 – PLATE |
3115348100 |
3115 3481 00 – BACK HEAD |
| 3115351181 | 3115 3511 81 – ACCUMULATOR |
| 3115354800 | 3115 3548 00 – NUT |
| 3115363501 | 3115 3635 01 – PISTON |
| 3115376800 | 3115 3768 00 – VALVE |
| 3115514601 | 3115 5146 01 – SEAL RING |
| 3115515200 | 3115 5152 00 – CONNECT. PLATE |
| 3115519000 | 3115 5190 00 – CUP SEAL |
3115527422 |
3115 5274 22 – INTERMED. PART |
| 3115527480 | 3115 5274 80 – INTERM. COMPL. |
| 3115527580 | 3115 5275 80 – SEAL HOUSE COMP |
| 3115531380 | 3115 5313 80 – ROT.CHUCK,COMPL |
| 3115531390 | 3115 5313 90 – CONVERSION KIT |
| 3115531400 | 3115 5314 00 – DRIVER |
| 3115534700 | 3115 5347 00 – SIDE BOLT |
| 3115535080 | 3115 5350 80 – COVER COMPL. |
3115535802 |
3115 5358 02 – LINER |
| 3115536000 | 3115 5360 00 – DISK SPRING |
| 3115561690 | 3115 5616 90 – CONVERSION KIT |
| 3115572400 | 3115 5724 00 – SIDE BOLT |
| 3115573700 | 3115 5737 00 – LABEL |
| 3115575701 | 3115 5757 01 – LABEL |
| 3115917090 | 3115 9170 90 – O-RING SET |
3115917092 |
3115 9170 92 – SEAL KIT |
| 3115923895 | 3115 9238 95 – OVERHAUL KIT |
| 3115923896 | 3115 9238 96 – OVERHAUL KIT |
| 3115923897 | 3115 9238 97 – OVERHAUL KIT |
| 3176651200 | 3176 6512 00 – NIPPLE |
| 3176651400 | 3176 6514 00 – NIPPLE |
| 3315019508 | 3315 0195 08 – LOCK WASHER |
7403091401 |
7403 0914 01 – SHANK ADAPTER |
| 7404091401 | 7404 0914 01 – SHANK ADAPTER |
| 7490516087 | 7490 5160 87 – SHANK ADAPTER |
| 7490516088 | 7490 5160 88 – SHANK ADAPTER |
| 7490516098 | 7490 5160 98 – SHANK ADAPTER |
| 7490516099 | 7490 5160 99 – SHANK ADAPTER |
| 7490516120 | 7490 5161 20 – SHANK ADAPTER |
7490516121 |
7490 5161 21 – SHANK ADAPTER |
| 7490516158 | 7490 5161 58 – SHANK ADAPTER |
| 7490516184 | 7490 5161 84 – SHANK ADAPTER |
| 7490516206 | 7490 5162 06 – SHANK ADAPTER |
| 7490516342 | 7490 5163 42 – SHANK ADAPTER |
| 9125619100 | 9125 6191 00 – O-RING |
| 9900000300 | 9900 0003 00 – PLASTIC BAG |
3115212200 |
3115 2122 00 – STOP RING |
| 3115212380 | 3115 2123 80 – STOP RING |
| 3115212900 | 3115 2129 00 – PISTON |
| 3115216300 | 3115 2163 00 – MANDREL |
| 3115219681 | 3115 2196 81 – TEST VALVE |
| 3115223100 | 3115 2231 00 – DRILL COLLAR |
| 3115212000 | 3115 2120 00 – FLUSHING HEAD |
For details about our product offerings, pricing, or potential partnerships, our sales team is ready to provide comprehensive information:
At ANWSK, we specialize in distributing the products of air compressors, mining machinery, drill rigs, mineral processing machinery, and related genuine original spare parts. These brands include Atlas Copco, Ingersoll Rand, Epiroc, Chicago Pneumatic, Sandvik, Sullair, Hitachi, CAT, BOGE, etc.
- Direct Sourcing & Authenticity:We source directly from manufacturers like Atlas Copco, CAT, etc. ensuring all spare parts are 100% original and new.
- Industry Expertise:With extensive experience across diverse sectors, we provide tailored solutions that enhance productivity and reliability.
- Comprehensive Support:We offer full-service support, including technical consultation, installation, maintenance, and emergency assistance.
- Commitment to Innovation:We stay updated with the latest advancements, providing cutting-edge technology for improved efficiency and sustainability.
ANWSK is your trusted partner for high-quality air compressor solutions, delivering value and reliability to every customer.
Inner packing:Poly bags
Outer packing:Export carton We deliver this item to worldwide via postal air mail, express, air transportation, sea shipping, etc.
Outer packing:Export carton We deliver this item to worldwide via postal air mail, express, air transportation, sea shipping, etc.
- If delivery time is not a critical factor and you prefer economical freight charges, you have the option of choosing postal air mail or sea shipping with a registered number. This method typically takes 15-30 days.
- For a quicker delivery, we offer express shipping through carriers such as DHL, UPS, FedEx, or EMS. While this service is fast, it comes with a higher cost, and you can expect delivery within 5-10 working days, including our Customs declaration for export.
For a quicker delivery, we offer express shipping through carriers such as DHL, UPS, FedEx, or EMS. While this service is fast, it comes with a higher cost, and you can expect delivery within 5-10 working days, including our Customs declaration for export.
1. Who are we?
Established in Guangzhou, China, we operate within diverse markets, with a significant presence in the Domestic Market(20.00%),Western Europe(15.00%),Southeast Asia(12.00%),Southern Europe(10.00%),North America(7.00%),Eastern Europe(7.00%),Northern Europe(5.00%),South
America(5.00%),Eastern Asia(5.00%),Mid East(5.00%),Oceania(3.00%),South Asia(2.50%),Africa(2.50%),Central America(1.00%). Our team, consisting of approximately 51-100 professionals, is dedicated to serving our customers worldwide.
2. Quality Assurance:
Ensuring top-notch quality is a cornerstone of our operation. We adhere to OE standards and subject every product to rigorous testing before shipment.
3.Our Product Range:
Explore our comprehensive selection, featuring air filter cartridges, air filters, oil/fuel filters, hydraulic filters, oil separators, air compressor parts, and more.
4. Why Choose Us:
What sets us apart is our unique history as a formerly state-owned enterprise with almost 30 years of expertise. We prioritize quality and offer competitive pricing, making us a reliable choice in the market.
5. Our Services:
- Delivery Terms: FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU, Express Delivery, DAF, DES
- Accepted Payment Currencies: USD, EUR, CNY
- Payment Types: T/T, MoneyGram, PayPal, Western Union, Cash, Escrow
- Languages Spoken: English, Chinese
Choose us for reliable products, quality assurance, and a diverse range of services tailored to your needs.
Answk Technology Co., Ltd was established in 2010 and has evolved into a versatile provider, specializing in mechanical and electronic products. Our technical team possesses 30 years of manufacturing experience, so factory prioritizes independent research and sources premium materials globally. Emphasizing quality control, we design major production machines in-house and offer specialized OEM and ODM services to meet custom needs across diverse industries, including the production of high- quality air compressor parts and related components, such as oil filters, air filters, oil/fuel filters, hydraulic filters, oil separators, air filter cartridges for cost-effective solutions.
We provide the products of original air compressors, mining machinery, drill rigs, mineral processing machinery, and related original spare parts from multiple brands (such as Atlas Copco, Ingersoll Rand, Epiroc, Chicago Pneumatic, Sandvik, Sullair, Hitachi, CAT, BOGE, etc.). We aslo manufacture the high-quality filtrations for air compressors, mining machinery, drill rigs, mineral processing machinery, etc.
Committed to innovation and excellence, Our Factory is a trusted partner for businesses seeking customized solutions. Our empowering OEM&ODM service leverages manufacturing expertise, seamlessly integrating your unique ideas into the production process. Whether it’s a specific design or product modifications, we deliver high-quality, bespoke solutions with precision and efficiency.
